JACK BLOCKS
86
JACKS AND PLUGS
PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
1/4" JACK BLOCKS
DUAL-JAX BLOCK ?
ORDERING
Order by part number from table.
Part Number
2300
2331
2332A
2332B
? 2333
Description
Block, without jacks.
Two, MT331 MT-Jax installed.
Two, MT332A MT-Jax installed.
Two, MT332B MT-Jax installed.
Two, MT333 MT-Jax installed.
? Special order only; contact Switchcraft for price and delivery.
Mounting Screws: #6-20, P1544, can be ordered separately,
Dual-Jax Blocks are ideal where limited jack connections are
needed but larger jack panels are not required. Designed for
broadcasting, intercom and PA systems, switchboards, and
commercial, industrial and military communications equipment.
Dual-Jax Blocks mount in panels or chassis, either singularly
or in multiples. Four countersunk holes accommodate four
#8-32 screws (not supplied) for block mounting. Blocks can be
supplied without jacks, or with MT-Jax ? installed. Many other
jacks including, T-Jax ? , T-Switch ? switches and lamp jacks can
be installed. Jacks with wire-wrapping terminals or offset lugs
can also be supplied. By drilling additional holes, Twin-Jax ?
may also be used. Contact Switchcraft for any special order items.
SPECIFICATIONS
Block: Molded black thermoplastic.
Screws: #6-20 plated steel, QQ-P-416, Type II,
Class 2 (for jack mounting).
contact Switchcraft.
SERIES 2300
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
